Function and Features:
Highly efficient extruder for aqua feed, food, pet food and raw material treatment, especially sticky formulations.
l Easy operation
PLC and touch screen for convenient control; by-pass provided for avoiding blockage; easy operation, precise and reliable.
l High efficiency
Optimal chamber groove and screw flight profiles, minimum SME input; efficient DDC conditioner and jacketed barrel with stabilized and facilitated extrusion, maximum energy utilization; unique suspending cutter, adjustment without down time.
l More flexibility
Modularized barrel and screw structure with many add-ons, adaptable to varied high-fat or -moisture formulations; controllable temperature, pressure and density, minimizing reconfiguration acquired.
Main Technical Parameters：
Model | SZTX150×2I | SZTX150×2 | YYSP150×2 | |
Capacity (t/h) | 3.5 - 6.0 | 6.0 - 7.5 | 7.5 - 10.0 | |
Power Of Main Motor (kw) | 160 - 6P | 200 - 6P | 315 - 4P | |
Conditioner Power (kw) | 11 + 15 | 11+18.5 | 11+22 | |
Feeder Power (kw) | 1.5 | 2.2 | 3.0 | |
Dia Of Rotor (mm) | 1500 | 1500 | 1500 |
Note: The above data only refers to aquafeed extrusion, for the other applications, please contact us.
